In-depth Analysis of the Deep Integration of the Core Principles of Ultrasonic C

Time:2025.04.22 Click-through rate:177

I. Analysis of the Core Physical Mechanisms of High-Frequency Vibration Cleaning

1. Acoustic Wave Spectrum Characteristics and Industrial Application Frequency Bands

Acoustic waves can be divided into three main frequency ranges according to frequency differences: infrasound waves, audible sound waves, and ultrasonic waves:


  • Infrasound waves (< 20Hz): Used for the monitoring of natural phenomena (such as seismic waves), with limited industrial applications.

  • Audible sound waves (20Hz - 20kHz): Within the human auditory range, used for sonar and communication.

  • Ultrasonic waves (> 20kHz): The core frequency band for industrial cleaning (20kHz - 1MHz), with two major technical advantages:

    • Directional energy transmission: With a short wavelength (37.5mm corresponding to 40kHz), the energy is concentrated in a micron-level area, enabling deep cleaning of precision structures.

    • Liquid penetration ability: It can penetrate a liquid medium of more than 100mm, meeting the cleaning requirements of complex structures such as deep holes and blind holes.

2. Analysis of the Three-Dimensional Collaborative Cleaning Effect

(1) Cavitation Effect — The Core Decontamination Power (Mainly 20kHz - 80kHz)

  • Dynamic process:

    • Negative pressure stage (-0.08MPa vacuum environment optimization): The distance between liquid molecules is increased, forming 5-50μm vacuum microbubbles.

    • Positive pressure stage: The microbubbles collapse instantaneously, generating a shock wave of over 1000atm, peeling off contaminants such as oil stains and metal debris on the surface of the workpiece.

  • Technical breakthrough: Vacuum degassing treatment increases the cavitation efficiency by 30%, which is especially suitable for the high cleanliness requirements of aerospace devices (surface particle residue < 3 pieces/mm²).

(2) Rectilinear Flow Effect — The Contaminant Transport System (Sound intensity above 0.5W/cm²)

  • Flow field characteristics: A directional liquid flow of 10-15cm/s is formed, driving the cleaning liquid to penetrate into slits smaller than 0.1mm, accelerating the mixing of the dirty liquid and the new liquid, and increasing the dissolution rate of oil-based contaminants by 35%.

  • Application scenarios: Cleaning of deep holes (> 150mm) in automotive engine blocks, ensuring a carbon deposit removal rate of > 98% (ISO 16232-10 standard).

(3) Particle Impact Effect — Precision Surface Treatment (High frequency band of 80kHz - 1MHz)

  • Action mechanism: Liquid particles obtain high-speed kinetic energy (> 5m/s), and remove nanoscale contaminants (such as 0.2μm particles on the surface of semiconductor wafers) through non-contact impact.

  • Technical advantages: The surface roughness is controlled to < 0.1μm, and the coating damage rate is < 0.01%, meeting the wafer-level cleaning requirements of the SEMI standard.

II. Equipment System Architecture and Innovation of Core Components

1. Upgrading of the High-Frequency Energy Conversion System

(1) Intelligent Ultrasonic Generator

  • Function enhancement:

    • Supports the complex frequency output mode (alternating between 28kHz rough cleaning and 40kHz fine cleaning), reducing the sound field blind area by 40%, and decreasing the cleaning dead angle rate of complex curved surfaces from 18% to 3%.

    • Dynamic power adjustment technology (accuracy ±5%), automatically matching the energy output according to the load, increasing the energy efficiency ratio by 15%, and reducing the risk of cavitation corrosion.

(2) Optimization Design of the Cleaning Cavity

The cleaning tank body is made of 316Ti stainless steel with stronger corrosion resistance. Compared with the traditional 304 stainless steel, its resistance to acid and alkali erosion is increased by about 60%, and it can be adapted to various strong acid and strong alkali cleaning media. The transducer adopts a matrix vibrating rod layout, combined with the design of the curved surface reflective tank wall, to achieve 360° omnidirectional sound emission. Through actual measurement, the sound field uniformity can reach more than 93%, effectively solving the problem of energy attenuation existing in traditional single-side vibrating box equipment. The supporting functional accessories include: a graded aperture mesh basket (0.5mm/1.0mm/2.0mm), which can meet the classification cleaning requirements of workpieces of different sizes; the anti-static fixture is made of a special material with a surface resistance < 10⁶Ω, providing reliable protection for the cleaning process of electronic components.

III. Optimization of Process Parameters and Intelligent Control System

1. Precise Control Strategy of Energy Density

Power Density (W/cm²)Applicable ScenariosCleaning Characteristic IndexSafety Threshold Control
0.3 - 0.8Precision optics/semiconductor componentsSurface damage rate < 0.01%Temperature ≤ 40°C (to prevent coating damage)
0.8 - 1.5Industrial metal parts/automotive partsOil removal efficiency > 98%, particle removal rate 95%Time ≤ 15 minutes (to prevent over-cleaning)
1.5 - 2.2Heavily polluted workpieces/castingsUsed in combination with chemical strengthening agentsVibration frequency ≥ 30kHz (to prevent metal fatigue)

2. Frequency Spectrum Adaptation Technology Matrix

(1) Low Frequency Band (20 - 40kHz)

  • Advantages: Strong cavitation effect, suitable for removing heavy oil stains and metal burrs.

  • Applications: Post-processing of 3D printing (removing residual powder in microholes, reducing the porosity to 0.3%), deburring of bearing rollers (surface roughness Ra ≤ 1.6μm).

(2) Medium and High Frequency Band (40 - 100kHz)

  • Advantages: Balanced cleaning power and surface protection, suitable for cleaning before precision assembly.

  • Applications: Removal of soldering flux on printed circuit boards (ion residue < 5ppb), decomposition of biofilms on medical implants (certified by AAMI ST79 standard).

(3) Megahertz Band (100kHz+)

  • Advantages: Mainly the acoustic streaming effect, non-destructive cleaning.

  • Applications: Wafer-level cleaning (0.2μm particle removal rate 99.8%), nanoscale purification of MEMS devices (surface energy maintained > 72mN/m).

3. Compatibility of Cleaning Media and Temperature Control

  • Aqueous system: Adding nanoscale surfactants (particle size < 50nm) to improve the microhole penetration efficiency, suitable for hydrophilic materials such as aluminum alloys and glass.

  • Composite solvent: Hydrocarbon solvent + chelating agent (metal ion capture rate > 99%), combined with a temperature control of 50-65°C, to accelerate the emulsification of stubborn grease (for example, reducing the engine carbon deposit cleaning time to 8 minutes).

  • Polymer protection: Plastic/rubber parts are cleaned at a low temperature of 35-45°C (to prevent deformation threshold), and a neutral cleaning agent (pH = 7-8) is used.

IV. Application Solutions and Case Demonstrations in the Whole Industry

1. Precision Manufacturing Field

  • Automotive powertrain: Using 40kHz complex frequency ultrasonic + alkaline cleaning agent, the cylinder block is cleaned in 8 minutes, the cleanliness reaches ISO 16232-10 level, and the assembly defect rate is reduced by 60%.

  • Aerospace components: The vacuum ultrasonic combined technology (-0.09MPa pressure) is used to clean the lenses of satellite sensors, with a surface particle residue < 1 piece/mm², meeting the weather resistance requirements of the space environment.

2. Electronic Semiconductor Industry

  • Wafer-level cleaning: 100kHz megahertz ultrasonic + deionized water, achieving a 0.1μm particle removal rate of 99.5%, meeting the SEMI F20 standard, and ensuring the yield of the lithography process > 99%.

  • Power chip packaging: The dynamic power adjustment technology (0.5W/cm²) is used to clean the lead frame, with an ion residue < 10ppb, reducing the risk of electromigration failure by 90%.

3. New Energy and Emerging Fields

  • Lithium battery electrodes: The integrated process of ultrasonic vibration + vacuum drying controls the metal impurities < 8ppm, and the battery cycle life is increased by 20%.

  • Optical medical devices: The 3D curved vibrating rod system is used to clean the endoscope lens, with a biofilm removal rate of 100% and a light transmittance maintained above 99.7%, meeting the ultra-clean requirements before sterilization.

V. Key Technologies for Sound Field Optimization and Energy Efficiency Improvement

1. Standing Wave Control and Cavity Design

The propagation uniformity of ultrasonic waves in the cleaning tank directly affects the cleaning consistency. The core control technologies include:


  • Wavelength matching design: According to the principle of "the distance between adjacent walls = an integer multiple of the half-wavelength of the acoustic wave" (for example, the wavelength of 40kHz ultrasonic waves in water is 37.5mm, and the recommended spacing is 75mm/112.5mm), the sound pressure distribution is pre-researched through the ANSYS sound field simulation software to ensure that the sound intensity difference in the tank < 10%.

  • Dynamic frequency scanning: Using the ±2kHz frequency conversion technology (such as dynamic switching between 28-30kHz), the energy blind area formed by standing waves is broken in real-time, and the cleaning dead angle rate of complex curved workpieces is reduced from 15% in the single-frequency mode to below 5%.

2. Innovation of Energy Efficiency Improvement Technologies

  • Vacuum ultrasonic coupling process: In a -0.08MPa vacuum environment, the gas content in the liquid is reduced by 40%, the cavitation threshold is decreased by 25%, and the cleaning efficiency is increased by 35% under the same power, which is especially suitable for the high cleanliness cleaning of aerospace-grade titanium alloy components (surface particle residue ≤ 2 pieces/mm²).

  • Optimization of the transducer layout: Using a 360° omnidirectional vibrating rod to replace the traditional single-side vibrating box, combined with the design of a 45° inclined tank wall, the sound field uniformity is increased from 75% to 93%, solving the problem of bottom cleaning of deep-hole parts (such as a 150mm long hydraulic valve body).

VI. Frequency Selection and Cleaning Scene Adaptation Technology Matrix

1. Full Frequency Band Application Guide Chart

Frequency RangeTypical Application ScenariosCavitation Bubble SizeCore Technical AdvantagesRepresentative Workpiece CasesCleanliness Standard
20 - 35kHzSand removal and deburring of castings80 - 150μmStrong impact force to break the metal adhesion layerAutomotive cylinder block/bearing ringISO 16232-9 level
35 - 60kHzRemoval of welding slag from electronic components and rough optical cleaning50 - 100μmBalanced penetration force and structural protectionPCB board/microscope objective lensIPC-A-610E Class 3
60 - 100kHzCleaning before precision component assembly20 - 50μmMicro-gap cleaning and surface coating protectionSemiconductor lead frame/medical catheterSEMI F20 particle size standard
100kHz+Nanoscale ultra-clean cleaning5 - 20μmNon-destructive cleaning and removal of molecular-level contaminantsWafer/MEMS sensorISO 14644-1 Class 1

2. Differentiated Process Parameter Configuration

  • Low frequency band (20 - 40kHz): The recommended power density is 1.2-2.0W/cm², with an alkaline water-based cleaning agent (pH = 10-13), suitable for removing stubborn contaminants such as engine carbon deposits and die-casting mold release agents. The cleaning time is controlled within 10-15 minutes.

  • Medium and high frequency band (40 - 100kHz): The power density is 0.6-1.0W/cm², using a hydrocarbon solvent (KB value > 60) + vacuum degassing treatment, suitable for cleaning before optical lens coating, ensuring that the surface residual oil < 0.1μg/cm².

  • Megahertz band (100kHz+): The power density ≤ 0.5W/cm², combined with deionized water + 0.1% nanoscale surfactant, achieving a 0.2μm particle removal rate of 99.8% for semiconductor wafers, meeting the requirements of extreme ultraviolet lithography (EUV) process.

VII. Technology Development Trends and Key Points of Engineering Practice

1. Integration Directions of Frontier Technologies

(1) Upgrade of Intelligent Control

  • Automated process system: The precise setting of cleaning parameters (frequency, power, time) is realized through a PLC programmable controller, supporting the linkage control of multiple tank bodies, adapting to the rhythm of the intelligent production line. In typical cases, the batch cleaning efficiency is increased by 40%.

  • Integration application of robotic arms: Equipped with a six-axis robotic arm to achieve automatic loading and unloading of workpieces, combined with customized fixtures (such as Teflon-coated anti-scratch fixtures), to meet the contactless cleaning of precision devices (such as optical lens groups), with a positioning accuracy of up to ±0.05mm.

(2) Innovation of Green Manufacturing Technologies

  • Closed-loop cleaning system: Using an integrated device of "ultrasonic cleaning - vacuum distillation - condensation recovery", the recovery rate of hydrocarbon solvents reaches more than 95%, reducing hazardous waste emissions by 60% per year, in line with the EU REACH regulations and the construction requirements of domestic "waste-free factories".

  • Water-based environmental protection process: Developing biodegradable surfactants (degradation rate > 90%), combined with 80kHz high-frequency ultrasonic, achieving an oil stain removal rate of 98% in the cleaning of aluminum alloy wheels, while avoiding the risk of heavy metal pollution of traditional solvents, meeting the environmental protection manufacturing standards of IATF 16949.

(3) Breakthroughs in Precision Cleaning Technologies

  • Application of megahertz ultrasonic: The cleaning technology in the high frequency band above 100kHz is mature. Using the acoustic streaming effect to achieve nanoscale cleaning (such as a 0.1μm particle removal rate of 99.5% on the surface of MEMS sensors), combined with a vacuum negative pressure environment, it can meet the ultra-clean requirements of extreme ultraviolet lithography (EUV) lenses (surface residue < 1 piece/mm²).

  • Integration of composite processes: Combining vacuum ultrasonic and supercritical CO₂ cleaning to achieve perfect cleaning without watermarks and chemical residues in semiconductor wafer manufacturing. After testing, the metal ion residue < 1ppb, significantly improving the chip yield.

2. Key Points of Engineering Practice Implementation

(1) Establishment of the Pretreatment Evaluation System

  • Analysis of pollutant composition: Detect the pollutant composition through a Fourier transform infrared spectrometer (FTIR) or a scanning electron microscope (SEM), and select the cleaning medium according to the situation — for example, for resin-based pollutants, a hydrocarbon solvent with a KB value > 70 is preferred, and for metal oxides, an alkaline water-based liquid (pH = 11-13) is recommended.

  • Material compatibility test: Conduct ultrasonic tolerance tests on new materials (such as silicon carbide and zirconia ceramics), record the safe threshold of power density (for example, for ceramic parts, it is recommended to ≤ 0.8W/cm²) to avoid cavitation corrosion.

(2) Equipment Selection and Parameter Configuration

  • Optimal selection of core components: Give priority to selecting cleaning equipment with complex frequency functions (28kHz + 40kHz) and vacuum degassing (-0.08MPa) to balance rough cleaning efficiency and fine cleaning accuracy. For example, after the automotive parts cleaning line adopts this configuration, the bearing cleanliness compliance rate is increased from 85% to 98%.

  • Standardized parameter library: Establish a corresponding table of "material - pollution type - process parameters" (for example, for titanium alloy parts: 30kHz frequency + 0.6W/cm² power + neutral water-based liquid), and optimize the cleaning time through the orthogonal test method (the recommended error is ±2 minutes) to reduce the trial-and-error cost.

(3) Equipment Maintenance and Accuracy Calibration

  • Monitoring of the transducer status: Regularly detect the impedance value of the transducer (recommended once a month). When the impedance deviation exceeds 15%, replace it in time to avoid a decrease in the cleaning effect caused by energy attenuation.

  • Calibration of the sound field uniformity: Use a hydrophone (accuracy ±0.5dB) to detect the sound pressure distribution in the tank to ensure that the sound intensity difference in each area < 10%. It is recommended to calibrate typical industrial-grade equipment once a quarter.

(4) Compliance Points of Industry Standards

  • Automotive industry: Follow the ISO 16232-10 cleanliness level. After cleaning, workpieces need to be detected by a particle counter (> 50μm particles ≤ 3 pieces/100cm²).

  • Semiconductor industry: Implement the SEMI F20 standard, control the particle residue above 0.2μm < 5 pieces/cm², and it is recommended to be equipped with a cleaning environment at the class 100 cleanroom level.

Conclusion

In the technological evolution of high-end manufacturing and precision machining, ultrasonic cleaning technology is changing from an auxiliary process to a core cleanliness treatment technology.
